Cảm biến lưu lượng Samson

Công ty TNHH Thương Mại Kỹ Thuật Hưng Gia Phát là nhà phân phối sản phẩm Samson Vienam

Mr Dũng : 0938 710079
Email: minhdung@hgpvietnam.com


Chúng tôi luôn tự hào là một trong những nhà cung cấp Samson Vienamhàng đầu chuyên dùng cho ngành công nghiệp trong các dây chuyền sản xuất và trong các hệ thống điều khiển hoạt động của nhà máy, xí nghiệp hay các sản phẩm của công nghệ cao và chất lượng.

Chúng tôi là công ty hàng đầu chuyên về Xuất Nhập Khẩu các thiết bị như:Samson Vienam , Relays, PLC, HMI, Inverter,Thiết bị đo nhiệt độ, áp suất, lưu lương, đo mức, motor, Pump…
































Samson Vietnam

Samson I/P Positioner


4763-0011 0012 110

(Model: 4763

Serial No: 001826

Part No. 4763-00110012110. 03)



Samson Vietnam

Water cooler thermoregulator "Samson" start to open: 60C +-2-72C-3 Dn 100. Valve type DN100, PN16, Kvs 125,housing EN-Jl 1040/A 126B, Flange type, thermostate type 2231 size 150, temp -10-+90st C, capillary 3m(4U)

Samson Vietnam

Water cooler thermoregulator "Samson" start to open: 50C +-2-62C-3 Dn 65. Valve type DN65, PN16, Kvs 50,housing EN-Jl 1040/A 126B, Flange type, thermostate type 2231 size 150, temp -10-+90st C, capillary 3m(4U)

Samson Vietnam

Samson Electric Actuator
Model: 3374-11
fail-safe action: Without
connection: For form fit-HVAC valves and V2001
thrust: 2500N stem extends, 2500N stem retracts
travel: 15mm
speed: Positioning speed 0.125mm/s
supply voltage: AC230V
frequency: 50Hz
positioner: With positioner 0(2)...10V/ 0(4)...20mA
switches: Without
Samson Electric Actuator
Model: 3374 11 (337411)
(Temperature Control Valve;
system: GAH (10 GPB + 3 IW),
model: 3374-11)

Samson Vietnam

Type: 3241 Valve
DN 50; PN 16; Body: Cast iron EN-JL1040 / A 126 B; Flanges
with raised face, Form B DIN EN 1092-2; Body gasket:
Graphite seal on metal core made of CrNiMo; Kvs 40 / Cv 47;
Equal percentage characteristic; 15 mm travel; Plug with
metal sealing (leakage class IV); Plug material 1.4006; Seat
material 1.4006; Seat with metal sealing; Packing
PTFE-carbon, spring-loaded; Connecting diameter 30 mm;
Bonnet for cast iron body
1015544
(SAMSON 32410 2 EN-JL 1040 DN50
PN16-558598 ;
POS.01-KV40
(control valve only))

Samson Vietnam

Type: 3767 Electropneumatic Positioner


Air connections ISO 228/1 - G 1/4; Electrical connection:

Cable gland M20 x 1.5 black (plastic); Reference variable

4...20 mA

Var- ID: 1046105

SAMSON 3767

Model 3767 - 00001220110000.06

Var- ID : 1046105

Serial No : 700618



Samson Vietnam

Type: 6116


input: 4...20mA

output: 0,2...1, bar

pneumatic connection: ISO-228/1 G1/4 electrical connection:

M20 x 1,5

IP65

weight: approx 2 KG

Note: item does not include flanges, screws and sealings



Samson Vietnam

Positioner 3730


Typ: 3730-1 with LCD and AUTOTUNE, command variable 4...20 mA, 2 software limit switches, hardware version GI 02, Software version 2.12

Var-ID: 2837382

(P poisoner

Model: 3730-1000000000000000000.02

O/P 4~20mA

Supply 6bar.90psi)



Samson Vietnam

Model: 3241-7 Control Valve


(3241-7 EN-JL1040 DN80

PN16

Description:

Valve 3241, DN80, PN16

- Body: type 3241 DN80; PN16;Cast iron

Flange raised face; Kvs 80/Cv 95

- Pneumactic actuator type 3277

range 0.4 to 2.0 bar

Valve closed without auxiliary power

- Postioner 3760

Pneumatic connections: 1/8 to 27 NPT

Cable gland: 20x1.5

reference variable 4 to 20 mA

- Mounting unit for type 3760)



Samson Vietnam

Type: 3241 Valve


DN 80; PN 16; Body: Cast iron EN-JL1040 / A 126 B;

Flanges with raised face, Form B DIN EN 1092-2; Body

gasket: Graphite seal on CrNiMo steel core; Kvs 80 / Cv 95;

Equal percentage characteristic; 15 mm travel; Plug with

metal sealing (leakage class IV); Plug material 1.4006; Seat

material 1.4006; Seat with metal sealing; Packing

PTFE-carbon, spring-loaded; Connecting diameter 30 mm;

Bonnet for cast iron body

1021195



Samson Vietnam

Type: 3277 Pneumatic Actuator


15 mm operating travel; Type 3277, diaphragm area 350

cm²; Diaphragm material NBR; Loading pressure

connection: ISO 228-1 G thread; Bench range 2.1 to 3.3 bar;

Fail-safe action "Stem extends"

1010623



Samson Vietnam

Type: 3760 Positioner


II 2 G EEx ia IIC T6 ATEX; Pneumatic connections 1/8 - 27

NPT; Electrical connection: Cable gland M20x1.5 black

(plastic); Type 6109 i/p Module; Reference variable 4...20

mA

1008202



Samson Vietnam

Mounting unit for Type 3760


Consisting of:; Mounting parts for direct attachment to Type

3277, 240 / 350 cm² (1400-6899); Range spring 1

(1400-6892); Zinc-plated steel piping; Direction of action:

Increasing / increasing

1012305



Samson Vietnam

Type: 4708 Supply Pressure Regulator


Type 4708-53 Supply Pressure Regulator, for mounting to

Types 373x/376x/378x Positioners (linear actuators);

Connection thread ISO-228/1, G 1/4; Set point range

0.5...6.0 bar, with pressure gauge (connection nickel-plated

brass); With 2 pressure gauges; Aluminum connecting part;

Filter in black plastic regulator body

1605388



Samson Vietnam

Model: 3241-7 Control Valve


(3241-7 EN-JL1040 DN80

PN16

Description:

Valve 3241, DN80, PN16

- Body: type 3241 DN80; PN16;Cast iron

Flange raised face; Kvs 80/Cv 95

- Pneumactic actuator type 3277

range 0.4 to 2.0 bar

Valve closed without auxiliary power

- Postioner 3760

Pneumatic connections: 1/8 to 27 NPT

Cable gland: 20x1.5

reference variable 4 to 20 mA

- Mounting unit for type 3760)



Samson Vietnam

Type: 3241 Valve


DN 80; PN 16; Body: Cast iron EN-JL1040 / A 126 B;

Flanges with raised face, Form B DIN EN 1092-2; Body

gasket: Graphite seal on CrNiMo steel core; Kvs 80 / Cv 95;

Equal percentage characteristic; 15 mm travel; Plug with

metal sealing (leakage class IV); Plug material 1.4006; Seat

material 1.4006; Seat with metal sealing; Packing

PTFE-carbon, spring-loaded; Connecting diameter 30 mm;

Bonnet for cast iron body

1021195



Samson Vietnam

Type: 3277 Pneumatic Actuator


15 mm operating travel; Type 3277, diaphragm area 350

cm²; Diaphragm material NBR; Loading pressure

connection: ISO 228-1 G thread; Bench range 2.1 to 3.3 bar;

Fail-safe action "Stem extends"

1010623



Samson Vietnam

Type: 3760 Positioner


II 2 G EEx ia IIC T6 ATEX; Pneumatic connections 1/8 - 27

NPT; Electrical connection: Cable gland M20x1.5 black

(plastic); Type 6109 i/p Module; Reference variable 4...20

mA

1008202



Samson Vietnam

Mounting unit for Type 3760


Consisting of:; Mounting parts for direct attachment to Type

3277, 240 / 350 cm² (1400-6899); Range spring 1

(1400-6892); Zinc-plated steel piping; Direction of action:

Increasing / increasing

1012305



Samson Vietnam

Type: 4708 Supply Pressure Regulator


Type 4708-53 Supply Pressure Regulator, for mounting to

Types 373x/376x/378x Positioners (linear actuators);

Connection thread ISO-228/1, G 1/4; Set point range

0.5...6.0 bar, with pressure gauge (connection nickel-plated

brass); With 2 pressure gauges; Aluminum connecting part;

Filter in black plastic regulator body

1605388



Samson Vietnam

Type: 44-8


DN 32; housing CC491K or CC499K (Rg5);

PN25; max temp 150°C; 1-4 bar; ∆p: 11 bar

(Type: 44-8 2720-02 1264199 0096

DN1”1/4; PN25

150oC;1-4 bar; ∆p: 11 bar)

Samson valves & control



Samson Vietnam

Type: 44-8


DN 50; housing CC491K or CC499K (Rg5);

PN25; max temp 150°C; 1-4 bar; ∆p: 11 bar

(Type: 44-8 2720-02 1306569 0096

DN2”; PN25

150oC;1-4 bar; ∆p: 11 bar)

Samson valves & control



Samson Vietnam

ID: 1653376 (1111715)


pneumatic actuator type 3372

with integrated i/p-positioner, i/p type

6109; G 1/4;

special version IP 65

(Control valve

Model: 3372-0511/9004.01)



Samson Vietnam

filter check valve in screw mounting housing G 1/2; IP 65


1790-7408



Samson Vietnam

Var-ID: 1008554


Limit Switch Type 4746

electrical, with electrical microswitches type

XGK 3 (silver contacts)

weight: approx. 0,7 kg/pc

(Model: 47466-03202X0.07

S.No: 700211)



Samson Vietnam

i/p-positioner type 3767


intrinsically safe Ex II 2 G EEx ia IIC T6 to

ATEX; air connections 1/4 - 18 NPT; electrical connection cable gland M 20 x 1,5 blue (plastic); reference variable 4...20 mA

Var-ID: 1591159 (1059000)

weight: ca. 1 kg/pc



Samson Vietnam

Var-ID: 1008623


Type: 4763 Electropneumatic Positioner

Intrinsically safe EX II 2 G EEx ia IIC T6 acc. to

ATEX; Lever I

(length 40 to 127 mm); Spring 2 (30 mm travel,

split range 15 mm); Pneumatic connections 1/4 - 18 NPT; Electrical connection: Cable gland M20 x 1.5, blue (plastic); Type 6109 i/p Module ; Reference variable 4-20 mA

weight: ca. 1,2 kg/pc



Samson Vietnam

ID: 1021195


Control Valve Typ 3241-7

DN 80; PN 16; Kvs-Wert 80 / Cv-Wert 95



Samson Vietnam

ID: 1010619


pneumatic actuator 3277

0,4...2,0 bar



Samson Vietnam

ID: 1634585 (1008180)


positioner type 3760

Pneumatic connections 1/8 - 27 NPT

Cable gland: 20x1.5



Samson Vietnam

ID: 1012305


mounting unit for Type 3760

Consisting of:; Mounting parts for direct attachment to Type 3277, 240 / 350 cm² (14006899); Range spring 1 (1400-6892); Zinc-platedsteel piping; Direction of action:

Increasing / increasing



Samson Vietnam

ID: 1605388


Type 4708 Supply Pressure Regulator

Type 4708-53 Supply Pressure Regulator, for mounting to Types

373x/376x/378x Positioners (linear actuators); Connection thread ISO 228/1, G ¼; Set point range 0.5...6.0 bar, with pressure gauge (connection nickel-plated brass); With 2 pressure gauges; Aluminum connecting part; Filter in black plastic regulator body



Samson Vietnam

ID: 1625194


Mounting unit for Type 4708

For Type 4708-53; Attached to a positioner;

Pneumatic supplementary connection in aluminum, ISO-228/1, G ¼ (1400-7400)



Samson Vietnam

Valve


Type: 3241

DN25;PN16

Var-ID: 1102350

(Valve DN25 - PN16, KV 10%

3241-1 EN-JL1040)



Samson Vietnam

Replaced by: 3241-7


Note: equivalent to the above positions, but complete mounted

(Valve DN25 - PN16, KV 10%

3241-1 EN-JL1040)



Samson Vietnam

Pneumatic actuator


Type: 3277

Var-ID: 1089719

(Pneumatic actutor 120 cm3

Var ID: 1089719

3277-031410910601010000.01)



Samson Vietnam

Controller


Type: 3767

Var-ID: 1046105

(Controller

var ID: 1046105

3767-00001220110000.06)



Samson Vietnam

Mounting set for 3766/3767


Var-ID: 1066572



Samson Vietnam

ID: 1605388


Type 4708 Supply Pressure Regulator

Type 4708-53 Supply Pressure Regulator, for mounting to Types

373x/376x/378x Positioners (linear actuators); Connection thread ISO 228/1, G ¼; Set point range 0.5...6.0 bar, with pressure gauge (connection nickel-plated brass); With 2 pressure gauges; Aluminum connecting part; Filter in black plastic regulator body



Samson Vietnam

ID: 1625194


Mounting unit for Type 4708

For Type 4708-53; Attached to a positioner;

Pneumatic supplementary connection in aluminum, ISO-228/1, G ¼ (1400-7400)



Samson Vietnam

Var-ID: 1008177


Type: 3760

pneumatic connections ISO 228/1 – G1/8;

electrical connection plastic cable gland M20x1.5: - Black; i/p type block 6109; reference variable 4 to 20 mA

weight: 0,6 kg/pc

(Positioner

Type : 3760-0012110)



Samson Vietnam

Var-ID: 1008177


Type: 3760

pneumatic connections ISO 228/1 – G1/8;

electrical connection plastic cable gland M20x1.5: - Black; i/p type block 6109; reference variable 4 to 20 mA

weight: 0,6 kg/pc

(Electropneumatic Positioner

3760-00012110-205633)



Samson Vietnam

Seat SB 110 DN 125 0110-2403


241/ 271/ 4763/ 4746 DN 125 pneum.

CA40580146

Note: could not be identified. Please send picture of

the nameplate of the valve.



Samson Vietnam

Compression spring DN 100-150


0270-1047



Samson Vietnam

Plug assembly, Kvs 200/Cv 230, %, 1.4404, DN 125, seat bore 110


1890-8009



Samson Vietnam

Wiper 16 x 22 x 3/4 NBR (16X22X3/4 NBR)


8429-0133



Samson Vietnam

Flat gasket - round DN125 PN16


241/ 271/ 4763/ 4746 DN 125 pneum.

CA40580146.

Kích thước: 141/192*2

Note: could not be identified. Please send picture of the nameplate of the valve.



Samson Vietnam

Seal


0430-0767



Samson Vietnam

Seal DN 200-400 PTFE Univer*** (PTFE)


0430-1100



Samson Vietnam

Graphite gasket 260 x 290 x 1.5, graphite/1.4401


8414-1510



Samson Vietnam

Diaphragm 1400 cm²


0520-0591



Samson Vietnam

Shaft sealing ring BA D 22 x 32 x 7 NBR, 1.4310


8406-0080



Samson Vietnam

Wiper, NBR / 1.4310


8429-0137



Samson Vietnam

Seat SB 150 DN 200, 1.4006


0110-4431



Samson Vietnam

Plug assembly, kvs 360, %, 1.4008 DN 200-250 SB 150


1690-3667



Samson Vietnam

Bushing DN 15-80, 1.4104


0310-0924



Samson Vietnam

Seat SB 24 DN 15-25 1.4006


0110-1791

(Seat KVS6,3/10 0100-1791

241/ 271/ 4763/ 4746 DN 25 pneum)



Samson Vietnam

Diaphragm 240 cm²


0520-0498



Samson Vietnam

Wiper 10 x 16 x 3/4,5 NBR


8429-0129



Samson Vietnam

Flat gasket - round


241/ 271/ 4763/ 4746 DN 25 pneum.

CA40580099

Note: could not be identified. Please send picture of

the nameplate of the valve.
